제품 소개방폭형 배기 팬

High Effciency 120-750w Explosion Proof Exhaust Fan With Vibration-damping Device Suitable For Zone 1,2

인증
중국 crown extra lighting co. ltd 인증
중국 crown extra lighting co. ltd 인증
제가 지금 온라인 채팅 해요

High Effciency 120-750w Explosion Proof Exhaust Fan With Vibration-damping Device Suitable For Zone 1,2

High Effciency 120-750w Explosion Proof Exhaust Fan With Vibration-damping Device Suitable For Zone 1,2
High Effciency 120-750w Explosion Proof Exhaust Fan With Vibration-damping Device Suitable For Zone 1,2 High Effciency 120-750w Explosion Proof Exhaust Fan With Vibration-damping Device Suitable For Zone 1,2 High Effciency 120-750w Explosion Proof Exhaust Fan With Vibration-damping Device Suitable For Zone 1,2

큰 이미지 :  High Effciency 120-750w Explosion Proof Exhaust Fan With Vibration-damping Device Suitable For Zone 1,2

제품 상세 정보:
원래 장소: 중국 장수
브랜드 이름: Crown Extra
인증: ATEX,CE,ROHS,CNEX,ISO9001
모델 번호: BFC
결제 및 배송 조건:
최소 주문 수량: 1PC
가격: USD51-93 per pc
포장 세부 사항: 상자 、 목재 상자 、 팔레트
배달 시간: 근무일 15 일
지불 조건: 티/티
공급 능력: 50000pcs/월

High Effciency 120-750w Explosion Proof Exhaust Fan With Vibration-damping Device Suitable For Zone 1,2

설명
제품명: 방폭형 배기팬 모델: 120~750W
마크: Ex db IIC T4 Gb 보호: IP54 WF1/WF2
RPM: 1450R/m CFM: 2000-9500m3/h
설치:
강조하다:

120-750w explosion proof exhaust fan

,

explosion proof fan with vibration damping

,

zone 1 2 exhaust fan

High effciency 120-750w explosion proof exhaust fan with vibration-damping device suitable for zone 1,2



BAG Series

High Effciency 120-750w Explosion Proof Exhaust Fan With Vibration-damping Device Suitable For Zone 1,2 0

Features

1. Zone 1&2, Zone 21&22

2. With explosion-proof motor
3. Strong anti-corrosion ability
4. Multiple installation methods
5..Different impeller speed or motor power, air flow for choice
6.Air duct of explosion proof axial flow fan is formed by welding of quality steel plate, and the fan blades are cast in aluminum alloy and with high voltage plastic-sprayed surface.
7. Aestheetic appearance, integrated ong-body assemble frame, safe and secure, with damping device and low-operating noise.



Technical Parameters:
Type BFC
Ex rate Ex d IIB T4 Gb
Degree protection IP54
Rated voltage 220/380VAC
Size of blade[mm] 300, 400, 500, 600
power consumption[w] 120; 180; 250; 370
Air volume[m³/min] 2200; 2400; 4900; 9500



Power 120-750w
Ex Mark Ex db IIC T4 Gb
Protection IP54 WF1/WF2
RPM 1450r/m
CFM 2000-9500m³/h
Diameter 200-500mm
Mounting wall

High Effciency 120-750w Explosion Proof Exhaust Fan With Vibration-damping Device Suitable For Zone 1,2 1



Type A B C
BFC-300 350 292 280
BFC-400 480 388 280
BFC-500 590 466 280
BFC-600 710 525 310





Installation Instructions:
Before installation, check voltage, power and other parameters carefully and
make installation preparations arrordingly to layout circuit.
1. organize firstly supporting spare parts and accessories
2. do shut off power before installation
3. the loading capacity of the ceilingfixed item where the lamp is installed should be the same as the lamp weight
4. do power-on test to make sure the lamp can be lighted
5. make sure the lamp is installed firmly, turn on the light finally
Company information:
Crown Extra Lighting Co., Ltd. is a comprehensive enterprise integrating R&D, production, sales and service.
The company is located in Changzhou, known as the "Dragon City" in the Yangtze River
Delta of China. The company is committed to becoming a provider of green, environmentally friendly,
energy-saving, and leading industrial lighting solutions, providing high-quality lighting products for
petroleum, petrochemical, electric power, metallurgy, railways, aerospace, military, public security,
fire fighting, ships, roads, pharmaceuticals, etc. And professional technical service programs.
FAQ:
Q1. Can I have a sample order for explosion-proof led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2: What kind of payments do you accept?
A:T/T, L/C, Western Union,, MoneyGram, etc..
Q3:What is you main products?
A: Explosion-proof LED light ,explosion-proof box,explosion proof fittings, etc.
Q4: Do you offer guarantee for the products?
A: Yes, we offer 3-5 years warranty to our products.
Q5: What's the MOQ?
A:MOQ is 1 set.
High Effciency 120-750w Explosion Proof Exhaust Fan With Vibration-damping Device Suitable For Zone 1,2 2High Effciency 120-750w Explosion Proof Exhaust Fan With Vibration-damping Device Suitable For Zone 1,2 3
