제품 상세 정보:
|
| Brand: | Crown extra | Product Name: | Explosion Proof Flood Light GYD970 |
|---|---|---|---|
| Model: | GYD970 | Voltage: | AC 100-277V,50HZ/60HZ:24/36VDC |
| Efficiency: | 130lm/w | CRI: | Ra:≥80 |
| CCT: | 3000/4000/5000/5700K | Mounting: | Street Light |
| Usage: | Industrial | Work Temperature: | -55℃~+60℃ |
| 강조하다: | ATEX explosion proof flood light,intrinsically safe LED street light,hazardous location square floodlight |
||
Outdoor explosion proof solar street light Ip66 100w 200w led flood light efficiency 130lm/w with five years warranty
GYD970 Series
Importance:
Inherent Safety Protection
Incorporates explosion containment and energy-limiting designs, meeting global certification requirements including GB3836 and ATEX standards. The engineered enclosure system prevents potential ignition by completely containing electrical discharges and thermal effects, removing combustion risks at their origin.
Operational Criticality
Maintains continuous operational safety for extractive and process industries. Delivers guaranteed illumination for crisis response scenarios while maintaining regulatory compliance in classified hazardous zones.
Performance Characteristics
Advanced solid-state lighting delivering 120-150 lumens per watt output
Optimized thermal management maintaining safe exterior temperatures
Severe environment capability with ingress protection up to IP67
Configurable with networked monitoring solutions
Applications
Energy and Power Facilities
Power Plants: Coal-fired Boiler Rooms, Gas Turbine Rooms
Substations: Underground Distribution Rooms, Battery Rooms
New Energy: Lithium Battery Production Workshops, Hydrogen Stations
Special Industrial Environments
Grain Processing: Flour Milling Workshops, Starch Drying Towers
Pharmaceutical Companies: Alcohol Extraction Workshops, Solvent Recovery Areas
Shipbuilding: Enclosed Cabins, Oil Tanker Pump Rooms
Public Safety Areas
Underground Utility Galleries: Gas Pipeline Layers, Integrated Pipeline Trench
Transportation Hubs: Subway Transfers, Airport Fuel Depots
Hospital Laboratories: Anesthetic Storage Rooms, P3 Laboratories
| Housing: | Die-casting aluminum |
| Exterior: | Stainless steel |
| Globe: | Tempered glass |
| Gasket: | Silicon rubber |
| Certifications |
ATEX
CNEX
CE
RoHS
ISO9001
|
| Rated voltage | 100-277VAC, 50-60Hz |
| Power factor | >0.95 |
| THD | <20% |
| Power consumption [W] | 50-75W, 100w,100-200w,250-300w |
| Colour rendering [CRI] | 70 (±2) |
| Colour temperature [K] | 6000-6500 |
| Luminaire efficiency[Lm/W] | 115-130 |
| Beam angle | 120° (60°, 90° is optional,with lens ) |
| Degree of protection | IP66 |
| Cable entry | G 3/4” |
| Weight [kg] | 5.12,9,12,20 |
| Terminal | ≤2.5 mm² |
| Mounting Styles | Ceiling; Wall Bracket; Pendant |
GYD970 Series
