Features:
◇environmental-friendly and eneray saving, simple shape, easy installation.
◇ constant current output, stable performance◇low power consumption, high light efficiency, good color rendering property
◇widely used in factories, warehouses, stadiums and other panoramic lighting.
| European(ATEX) | CE 1282 II 2G Ex n Re mb IIC T6 | |||
| Gas and Dust | CE1282 II 2D Ex td T80℃ | |||
| For use in | Zone 2& Zone 21,22 | |||
| Rated voltage | 100-240VAC, 50-60Н2 | |||
| Power factor | >0.95 | |||
| THD | <20% | |||
| Power consumption [W] | 50-75 | 100 | 100-200 | 250-300 |
| Colour renderina [CRI] | 70 (+2) | |||
| Colour temperature [K] | 6000-6500 | |||
| Luminaire efficiency [Lm/W] | 115-130 | |||
| Beam angle | 120° (60°,90° is optional, with lens) | |||
| Deqree of protection | IP66 | |||
| Cable entry | G 3/4" NPT 3/4" | |||
| Weight [kg] | 5.12 | 9 | 12 | 20 |
| Terminal | ≤2.5m㎡ | |||
| Mounting Styles | Ceiling; Wall Bracket; Pendant | |||
Installation:
Before installation, Check voltage, power and other parameters carefully and make installation preparations arrordingly to layout circuit.1. organize firstly supporting spare parts and accessories.2. do shut off power before installation.3. the loading capacity of the ceiling fixed item where the lamp is installed should be the same as the lamp weight.4. do power-on test to make sure the lamp can be lighted.5. make sure the lamp is installed firmly, turn on the light finally.
